Built for offroad! With a 40mm Zoom suspension fork, the Spyke 20 D is the perfect first mountain bike for your youngster. Featuring 2'35" knobbly mountain bike tyres and a Shimano 1 X 6 drivetrain, this bike is suitable for riding trails, street, your local pump track or even to school and back. Spyke features smaller contact points to suit smaller hands and shorter legs, and disc brakes brakes ensure reliable braking performance.

MECHANICALLY-FORMED 6061 ALLOY FRAME

Spyke 20 features a frame optimized for young riders. Trickle-down technology means that the new frame benefits from our leading platforms. The frame tubes are mechanically formed into complex shapes to increase strength and stiffness, minimizing weight and excess material use, resulting in a lighter weight frame and lighter complete bike.

SUSPENSION FORK

The lightly sprung Zoom 40mm Suspension fork is ample for smaller riders, smoothing out uneven terrain as well as improving grip adding loads to the fun factor on bumpy trails or jumps

KEY FEATURES

Silverback 20" 6061 Aluminium, Low standover frame, 1-1/8" Headtube
Zoom steel suspension fork with 40mm of travel
20" Alloy single wall rims, 20H with steel spokes, 2.35" tyres
Disc brakes
Kick stand
Easy ride geometry
Size specific contact points
Weight: 12.64 kg

FRAMESET
Frame	New Spyke 20 Frame, Updated Geometry and formed tubing, 6061 Alloy, 1 - 1/8" HT, IS Disc Tabs
Headset	1-1/8" Headset, Press in cups
Frame Axle Spacing	130 X 9mm
Frame Specification	QR
Hanger Type	HANGER 05
SUSPENSION
Fork	Zoom Steel suspension fork, 40mm travel, Coil
Fork Travel	40mm
WHEELS
Wheelset	SURFACE Custom Wheelset
Hubs	F: Alloy, 24H, 100 x 9mm, 6-bolt Disc, QR
Hubs	R: Alloy, 24H, 135 x 9mm, 6-bolt Disc, QR
Rims	F: 20" Alloy Single Wall, 24H
Rims	R: 20" Alloy Single Wall, 24H
Tyres	F: 20 x 2.35" Wanda P1226
Tyres	R: 20 x 2.35" Wanda P1226
Max Tyre Size	2.35"
DRIVETRAIN
Crankset	Alloy, 127mm, 32T chainring
Max Chainring Size	36T
Bottom Bracket & Type	BSA68
Shifter(s)	R: Shimano SL-RV300-7R, 7-speed
Rear Derailleur	Shimano Tourney RD-TY500, 7 Speed
Cassette	Shimano CS-HG200 12-28T, 7 speed
Chain	Shimano CN-HG40 for 7 Speed
BRAKES
Brakes	F: Tektro MD-M280 Mechanical Disc
Brakes	R: Tektro MD-M280 Mechanical Disc
Rotors	F: 160mm, 6-bolt
Rotors	R: 160mm, 6-bolt
COCKPIT
Grips	110mm Long, Grip Shift
Handlebar	Alloy, 580mm x 25.4, 10°, H:15mm
Stem	Alloy, 25.4mm E:60mm H:41mm 15°
Saddle	Spyke kids
Seat Post	Alloy, 27.2mm x 250mm
Seatpost Clamp	Alloy, 31.8mm, QR
Pedals	9/16″ Ball, PP
WEIGHT
Bike Weight	12.64 kg
RIDER WEIGHT LIMIT	120kg - combined weight of bike and rider (including all kit).
